Choosing the type of microgrid that is right for your operation

Jan. 16, 2018
So you’ve decided that your operation needs a microgrid. But what type of microgrid? Here’s a guide to your choices in the latest installment of the Microgrid Knowledge “About Microgrids” series.

So you’ve decided that your operation needs a microgrid. But what type of microgrid?

Answering that question isn’t always easy because microgrids come in many different permutations, often customized to the business, factory, hospital, university, community or other operation they serve. But they do fall into certain broad categories, sliced and diced in various ways, including by type of grid connection, owner, developer and fuel, as well as purpose, function and sophistication.

As part of our About Microgrids series, this article explains some of the various categories. Understanding what’s available will help you identify the type of microgrid right for your operation.

Remote versus grid-connected microgrids

Microgrids are categorized most broadly by their grid interface, of which there are two choices. A microgrid is either grid connected or remote (not linked to the grid).

Remote microgrids often are found on islands or in isolated areas of the world that lack a central utility grid — or at least one that is reliable. You’re likely to find remote microgrids in rural Africa, the Himalayas, islands, military combat zones and other isolated locations. Remote microgrids operate independently; they rely solely on their own generators to keep the power flowing to customers.

Grid-connected microgrids, on the other hand, can work with a central grid. They choose to take service from the grid or use their own internal generators to serve their customers.

An advanced microgrid controller — the brain of the system — “decides” at any given moment which energy source is most advantageous, given moment-to-moment changes in electricity pricing, resource availability (e.g., is the sun shining on solar panels?) and other factors. These decisions are based on programming priorities set by the microgrid owner. For example, if the owner is trying to achieve climate goals, the microgrid will seek the mix of available energy resources that offers the lowest carbon emissions. Others might prioritize for price or electric reliability.

Interested in microgrids? Join us at Microgrid 2022: Microgrids as Climate Heroes June 1-2 in Philadelphia, Pennsylvania, for an array of educational discussions by the top experts in microgrids.

Grid-connected microgrids offer another benefit – they can take advantage of opportunities to accrue revenue from the grid. They may sell energy and ancillary services back to the grid (depending on the regional grid operator rules). Or they might participate in utility demand response programs.

A grid-connected microgrid isn’t always grid connected. If a power outage occurs, the microgrid disconnects from the central grid. This is called “islanding.” The microgrid relies on its own generators and perhaps an energy storage system until the power outage is over. At that point it reconnects to the grid. If the microgrid has an advanced controller, this all happens with no human intervention. Customers will be unaware of any change.

By metamorworks/Shutterstock.com

Given the many benefits of having a link to the grid, it’s not surprising that most microgrids in the lower 48 states are grid connected.

Advanced or basic

Microgrids can employ many different forms of generation. Within their geographic footprint some have solar, batteries, combined heat and power, diesel and natural gas generators. Each is coordinated to turn on and off based on the microgrid’s programming.

Others are far simpler, perhaps using only one or two types of energy, like a natural gas generator or solar plus a battery.

Microgrids also may serve one building or many buildings.

The number of generators they employ and the number of customers they serve typically defines where they are on the scale of advanced to basic.

Fuel

Those just beginning to consider what type of microgrid they want often focus on fuel type. This is especially true of customers trying to achieve sustainability goals. So the industry often describes microgrids in terms of fuel. Thus, we have solar microgrids, solar plus storage microgrids, wind microgrids, CHP microgrids, district energy microgrids, diesel microgrids, natural gas microgrids, waste-to-energy microgrids, fuel cell microgrids and others.

It’s important to note that advanced microgrids typically have more than one form of energy. This is one of the things that makes a microgrid highly reliable. So a project described as a solar microgrid, for example, likely has a battery or fossil fuel generator (or both) on-site as well.

The microgrid’s purpose

By Gorodenkof/Shutterstock.com

Microgrids also may be described in terms of their primary purpose or who they serve. A cybersecure microgrid is designed with particular attention to averting hackers. That doesn’t mean the microgrid achieves only that. A cybersecure microgrid can — and likely will — also undertake other microgrid functions, such as ensuring reliable energy or managing electricity pricing.

A community microgrid usually serves critical facilities in a town or city and often has some government funding. Its primary purpose is to ensure power to services that people can’t live without for an extended period of time. These include hospitals, police and fire stations, shelters, grocery stores, gas stations, waste and water treatment facilities and communication infrastructure.

Commercial and industrial (C&I) microgrids are among the fastest growing. As the name implies they are built for businesses, often via private funding. C&I microgrids serve manufacturers, office parks, retail and grocery stores, data centers and any other business that wants to avoid power outages, manage energy efficiently and reduce energy costs.

Construction

Microgrids can be stationary or mobile. Most microgrids stay in one place. But the military sometimes employs mobile units that it can move from base to base in war zones. These tend to be relatively simple solar plus storage units that can be constructed on-site quickly.

Modular microgrid” is another term increasingly used. This describes microgrids designed to be gradually expanded over time in a Lego fashion.

Type of microgrid based on owners/developers

Microgrids sometimes take their name based on who owns or develops them. Thus we have military microgrids, utility microgrids, campus microgrids and institutional microgrids.

This is just a sampling of the types of microgrid projects available. The market continues to differentiate as it grows. Microgrids are now described, for example, in terms of the kind of financing they offer, as in reliability-as-a-service microgrids. There are also direct current and alternating current microgrids, virtual microgrids, blockchain microgrids, residential microgrids and others. We invite you to contribute examples in the comments section below.

What type of microgrid might be right for your operation? Learn more by attending Microgrid 2018
